Turn Signal / Fog / Reverse / Marker Light Wiring Harness for Passenger & Commercial NEVs

Name: Passenger & Commercial NEV Wiring Harness for Turn Signal, Fog, Reverse, and Marker Light Bulb Sockets
Brand: Wire Harness Works
SKU: AUTO-04
Availability: InStock

Custom-engineered bulb socket wiring harness for turn signal, fog, reverse, marker, and position light applications across passenger cars, commercial vehicles, and New Energy Vehicle platforms. Fully automatic cold-press manufacturing with 3C certification.

Pure Copper V-0 Flame Retardant 3C Certified IATF 16949

Product Series

Marker Bulb Socket Harness

Voltage Rating

12V – 24V DC

Wire Gauge

0.35 – 2.0 mm²

Conductor

Pure Copper

Insulation

PVC, V-0 Flame Retardant

Process

Cold Press · Fully Automatic

Certification

3C Certified · IATF 16949

Request a Quote Chat on WhatsApp

3C Certified · UL94 V-0 flame retardant · Compatible with passenger cars and commercial NEVs · 24-hour quote response.

Product Description

Engineered for Vehicle Signal Lighting Systems

The Turn Signal / Fog / Reverse / Marker Light Harness is a custom-engineered bulb socket cable assembly designed for the signal lighting systems of passenger cars, commercial vehicles, and New Energy Vehicles. Each harness is pre-terminated with the bulb socket and downstream connector your platform requires — plug-and-play installation with no field crimping.

Manufactured in our IATF 16949 certified facility in Shenzhen using fully automatic cold-press terminal crimping, every harness uses pure copper conductors with PVC insulation rated UL94 V-0 flame retardant. The product line is 3C certified for both domestic and export use.

Suitable for the full range of vehicle signal lighting positions: front turn, rear marker, position lights, step lights, high-mount marker / turn signals, and standard vehicle marker lights. Every parameter is customizable — bulb socket type, connector brand (TE, Molex, JST, Yazaki, Sumitomo), pin count, wire color coding, cable length. Send your drawing or sample — receive a manufacturable quote within 24 hours.

Key Features

Why OEMs Choose This Harness

Pure Copper Conductors

Solid pure copper wire (no copper-clad aluminum) for maximum conductivity, low signal loss, and durable crimping integrity.

UL94 V-0 Flame Retardant

PVC insulation self-extinguishes within 10 seconds — meets automotive and industrial fire-safety standards worldwide.

3C Certified Product Line

China Compulsory Certification confirms this product line meets all required safety, quality, and emissions standards for domestic and export markets.

Fully Automatic Cold Press

Computer-controlled crimping equipment delivers consistent terminal force on every connection — eliminating the variability of manual crimping.

100% Tested Before Ship

Every harness undergoes continuity test, hi-pot test, and visual inspection. Test reports provided per batch on request.

Full Customization

Bulb socket type, connector brand, pin count, wire gauge, color coding, sleeving, length — all customized to your drawing or sample.

Full Specifications

Technical Parameters

Product Series	Marker Light Bulb Socket Custom Harness
Product Category	Vehicle Signal Light Wiring Harness
Manufacturing Process	Cold Press · Fully Automatic · Customizable
Contact Material	Pure Copper
Insulation Material	PVC (Polyvinyl Chloride)
Wire Gauge Range	0.35 mm² – 2.0 mm²
Operating Voltage	12V – 24V DC
Operating Temperature	-40°C to +140°C
Flame Retardant Rating	UL94 V-0 (self-extinguishing within 10 seconds)
Product Certification	3C Certified (China Compulsory Certification)
Quality System	IATF 16949, ISO 9001, RoHS, REACH
Connector Pin Count	Customizable per drawing
Compatible Connector Brands	TE Connectivity, Molex, JST, Yazaki, Sumitomo, JAE
Application Scope	Front Turn / Position / Rear Marker / Step / High-mount Marker-Turn / Vehicle Marker Lights
Vehicle Applications	Passenger Cars, Commercial Vehicles, NEV / EV Platforms
Order Code	AUTO-04
Minimum Order Quantity	10 pieces (sample); 500+ pieces (production)
Lead Time	7 – 15 days (sample); 20 – 35 days (production)
